立体声 8Ω输出功率 Stereo 8Ω Output Power | 1350W+1350W |
立体声 4Ω输出功率 Stereo 4Ω Output Power | 2100W+2100W |
桥接8Ω输出功率 Bridge 8Ω Output Power | 4200W |
输出连接器 Output Interface | 2 Speakon for Stereo & Bridge Output |
频响范围Frequency Response | 20Hz-20kHz, -0.5dB |
输入灵敏度Input Sensitivity | 0.77V |
平衡输入阻抗Balanced Input Impedance | 20kΩ/Balanced, 10kΩ/un-Balanced |
信噪比SNR | ≥95dB |
失真度Distortion | ≤0.03 |
额定输出功率8Ω 1kHz时分离度 Rated Output Power 8Ω 1kHz Resolution | ＞70dB |
阻尼系数f=1kHz 8Ω | ＞240 |
转换速率Conversion Rate | 15V/uS |
保护Protection | Soft Start, Short Circuit, Limiter, DC Fault, AC Line Fuse, Thermal Cut |
冷却系统Cooling System | 双风扇Two Steps Speed Fan |
电源Power | AC: 220-230V 50Hz/60Hz |
净尺寸（宽×深×高）Dimensions (WxDxH) | 480mm×510mm×130mm |
净重量Net Weight | 32.7kg |
